Stack Height Above Roof

This is for masonry chimneys.

Stack height above roof.

For a gas vent or type l vent this height must be 2 ft 0 61m or more. Place the stack at least 10 ft high on most roofs to avoid recirculation. National fire protection association nfpa standard 45 specifies a minimum stack height of 10 ft to protect rooftop work ers. I ve seen anywhere between 6 18 depending on location for minimum stack height above a roof.

Tester101 jan 17 12 at 16 21. Back to our example over a run of 10 feet the roof would rise 40 inches. Keep in mind however the minimum height is the length of the shortest side of the pipe. So take the top number of your roof pitch and multiply it by 10 then add 24 note example 1.

E height limit applies to r2 zone located within the hillside area and non hillside area except within the coastal zone. Additionally per our rule we need to add 2 feet or 24 inches giving us a total height of 64 inches. Where a roof is used for any purpose other than weather protection vents shall extend at least 7 feet above the roof and shall be properly supported. In the r1 variation zones r1v r1f and r1r the height limits shall comply with section 12 08c 5 b d.

F in the r1 zone height limits are as stated in the chart no 1 above. Each vent pipe or stack shall extend through its flashing and shall terminate vertically not less than 6 inches 152 mm above the roof nor less than 1 foot 305 mm from a vertical surface. Stack height ansi aiha standard z9 5 10 ft above adjacent roof line standard nfpa 45 minimum 10 ft height to protect rooftop workers nfpa 92a exhaust stack discharge location should be away from building outside air intakes to minimize recirculation. Provide a stack velocity of a minimum of 1 4 times the wind velocity.

A vertical line drawn along the up roof side of the chimney from the roof surface to the top of the chimney flue opening shall be at least 3 ft in height. Standard z9 5 recommends a minimum stack height of 10 ft above the adjacent roof line an exhaust velocity v e of 3000 fpm and a stack height extending one stack diameter above any architectural screen. Place the stack as far from the intake as possible 50 ft is recommended. Provide ample stack height a minimum of 10 ft above adjacent rooflines or air intakes.

The top of the flue opening should be 3 ft 0 92 m above any roof surface.
